Page 332 - BallyMidway YELLOW Parts Catalog 16-9147-B

SEO Version

(20013)
Wireform and Ball Gate Locations
Item Part Number
Description
1 12-6842
Bottom Arch Wire Fence
2 12-6866-9
Wireform Guide,
2-1/4"
(2)
3 A-14827
Crossover Wire Ramp Ass'y
4 A-15132
Switch Gate Assembly
5
A-14042
Switch Gate Assembly
6 A-15133
Switch Gate Assembly
7 A-14868
Ball Gate Assembly
8 A-15131
Ball Gate Assembly
9 12-6466-8
Wireform Ball Guide, 2"
10 A-15281
Switch Gate Assembly
11 A-15043
Center Wire Ramp Ass'y
Under Bottom Arch:
12 A-8645
Rollover Wire & Brkt Ass'y
13 A-5844-44
Rollover Wire & Brkt Ass'y
14 A-5844-45
Rollover Wire
&
Brkt Ass'y
15 12-6542
Ball Return Gate Wire
4-Si
