Page 327 - BallyMidway YELLOW Parts Catalog 16-9147-B

SEO Version

(20009)
Wireform, Ball Gate & Spin Target Locations
Item Part No.
Description
12-6842
Bottom Arch Wire Fence
1a 12-6961
Wi reform, 3/4"
2
12-6466-14 Wi reform, 3-1/2"
3 12-6466-10 Wireform, 2-1/2"
4 8-13487
Ball Gate Assembly
5 12-6955
Wireform,4"
6 12-6466-3
Wireform, 3/4"
7 A-14158
Switch Gate Assembly
8
12-6466-5
Wireform, 1-1/4"
9 A-9465-L
BaHGate Assembly
10 12-6466-3
Wireform, 3/4"
11 12-6954
Curved Wireform
12 12-6466-8
Wi reform, 2"
13 12-6956
Wireform, 9"
14 8-12164-1
Sp.inTarqet Assembly
Under Bottom Arch:
15 A-8645
Rollover Wire
&
Bracket Assy.
16 A-5844-44
Rollover Wire
&
Bracket Assy.
17 A-5844-45
Rollover Wire
&
Bracket Assy_
18 12-6542
Ball Return Gate Wire
