Wireform and Ball Gate Locations
Item Part No. Description
1 12·6842 Bottom Arch Wire Fence
2 12-6952 Left Ball Popper Wire Ramp
3 12-6466-5 Wireform, 1-1/4"
4 A-14073 Ball Gate Assembl~
5 12-6466-17 Wireform, 4-1/4"
6 12-6466-20 Wire form, 5"
7 12-6466-15 Wireform, 3-3/4"
8 A-13100-1 Ball Gate Assembly
9 12-6942 Wireform Ball Guide
10 12-6922 Right Ball Popper Wire Ramp
'1 12-6923 Mixmaster Wire Ramp
12 A-14089 Ball Gate Assembly
13 12-6466-2A Wire form, 518" (3 used)
Under Bottom Arch:
14 A·8645 Rollover Wire & Bracket Assy.
15 A-5844-44 Rollover Wire & Bracket Assy.
16 A-5844-45 Rollover Wire & Bracket Assy.
17 12-6542 Ball Return Gate Wire
