Page 163 - BallyMidway YELLOW Parts Catalog 16-9147-B

Speaker Panels - cont'd
o
;- - - - -- - - - - - - - -- - -- - - - - -- - -- -- 1
, I
I I
I
I
I
I
'A-15212 A-15823
Item Part Number Description Item Part Number Description
~ B-13826-3 Ground Lug Ass'y ~2" 1 B-13826-3 Ground Lug Ass'y 12"
2 0-12501 7-Lamp PCB Ass'y 2 A-1S805 7-Lamp PCB Ass'y
3 H-15011 Speaker Cable Ass'y 3 H-15011 Speaker Cable ASs'y
4 01-8535 Latch Bracket (2) 4 01-8535 Latch Bracket (2)
5 01-10056 Dot Matrix Shield 5 01-10056 Dot Matrix Shield
6 ·03-8265-1 Speaker Panel Bracket 6 03-8265-1 Speaker Panel Bracket
7 31-1420-20017 Screened Panel Cover 7 31 -1420-20006 Screened Panel Cover
8 5045-12914-00 Capacitor .1Omfd 50V 8 5045-12914-00 Capacitor .1Omfd 50V
9 5825-09372-00 #6 Solder Lug. Bent 9 5825-09372-00 #6 Solder Lug. Bent
10 5901-12784-00 Dot Matrix Display 10 5901-12784-00 Dot Matrix Display
Note: See p. 2-18 for Speakers.
