Knocker Assemblies
A360-00235-0000
8-10686-1
1
Item Part No.
Description
Item Part No.
Description
1 A360-00011·00XF Plunger & Striker
1 8-7409-2
Mounting Bracket
2 A360-0004S-0000 CoilITB: 2 Lug
2 AE-23-BOO
Coil Assembly
.
3 0010-00274-0212 Compress. Spring
3 23-6420
Rubber Grommet
4 0017-00041-0635 Black Plug Bumper
4 A-S387
Coil Plunger Assembly
5 0360-0031S-0DXF Coil Bracket
5 01-S-508-T
Coil Retain Bracket
6 0360-00909-00XF Coil Frame
(Under Coil Asy.)
7 4008-01015·04B
n
#8-32 x
1/4P
6
4008-01017-06
Machine Screw
8
4705-00002·00
Spring Washer
7 H-11835
Knocker Cable
(Under Coil Asy.)
Knocker Assembly
Trek Game Atla Tran Mous Elvi
Part Number
2001 2003 2006 2008 2009 2011
A360-00235-0000
x
x
B-10686-1
x
x
x
x
Note: Knocker Assembly for Truck Stop (2001) is located under the Playfietd. (See p. 5-33)
@af!tt/MIDWAY
2-15
