Page 135 - BallyMidway YELLOW Parts Catalog 16-9147-B

Ball Shooter Asse-mbly
Trek Game Alia Tran Mous Elvi
Part Number Description 2001 2003 2006 200S 2009 2011
Game and Part Quantity
,
8-12445-1 Ball Shooter Assembly 1 1 1 1 1 1
w/10-148-1 Shooter Spring, Silver
Pool Radie Dude Harl Bugs
Part Number Description 2014 2015 2016 20001 20009
Game and Part Quantity
8-12445-1 Ball Shooter Assembly 1 1 1 1
w/1 0-1 48-1 Shooter Spring, Silver
8-12445-3 8all Shooter Assembly 1
w/10-148-3 Shooter Spring, Blue
Gillign PartyZ DrWho BlackR Addam
Part Number Description 20003 20004 20006 20013 20017
Game and Part Quantity
B-12445-1 Ball Shooter Assembly 1
w/10-14S-1 Shooter Spring, Silver
8-12445-3 Ball Shooter Assembly 1
w/10-148-3 Shooter Spring, Blue
8-12445-4 Ball Shooter Assembly 1 1
w/10-148-4 Shooter Spring, Green
Note: Dr. Who (20006) uses a Ut Switch Button (see p. 5·96).
@af!tt/MIDWAY
