BOTTOMPlAYFIElD ASSEMBLY - PARTS LIST
PART NO. AE94-00004-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION --- -j
1 AC70-00022-0100 FLIPPER ASSY. SINGLE SWIRl (SEE PAGE 22 )
---
2 AC70-00022-0200 FLIPPER ASSY. SINGLE SWILl (SEE PAGE 20)
3 AC70-00023-0100 FLIPPER ASSY. DOUBLE SWIRl (SEE PAGE 24)
4 A.C70-00023-0200 FLIPPER ASSY. DOUBLE SW/LT ("SEE PAGE 26 )
5 AE94-00005-0000 PLAYFIELD CABLE ASSY.
AE94-00038-0000 TOP PLATFORM ASSY. (INCLUDES ITEMS 6 THRU 13)
6 AE94-00033-0000 DROP TARGET ASSY. 3 IN-LINE (YELLOW) (SEE PAGE 27)
7 AE94-00035-0000 DROP TARGET ASSY~ 3 SIOE-BY-SIOE (ORANGE) (SEE PAGE 30)
8 AE94-00042-0000 TARGET W/SPECIAL MOUNTING BRKT. RED
A365-R0300-0111 TARGET, S~HTCH , DIODE & CAP ASSY. RED LUG-RT.
A360-00070-0000 SWITCH ASSY. : TARGET, LUG-RT.
9 A365-R0307-F114 TARGET, SWITCH, BRKT •• DIODE & CAP: GREEN LG-RT.
A365-R0300-0004 TARGET W/SWITCH ASSY. : GREEN LUG-RT. (3 REQ 10. )
A360-00070-0000 SWITCH ASSY. : TARGET. LUG-RT. (3 REQID.)
10 A331-00042-0000 BRKT. W/HIRE-FORM ASSY. ROLLOVER LT. (2 REQ 10 ~)
Q360-00135-0000 BRKT. : ROLLOVER-WIRE, LT.
0360-00929-0200 WIRE-FORM: ROLLOVER, LT.
11 A360-00239-0000 SWITCH W/BRKT. & DIODE ASSY. : SL INGSHOT (2 REQ I D. )
A360-00069-0000 S~IITCH ASSY.
12 A365 ...00035 ...0000 SWITCH W/DIODE & PLATE ASSY. (2 REQ ID. )
A360-00243-0000 SWITCH W/DIODE ASSY.
A360-00061-0000 S~IITCH ASSY.
13 SEE COMMON SOCKET ASSY. (SEE PAGE 40)
14 AE94-00040-0000 BALL SAVER ASSY. LT. (SEE PAGE 33)
6.10
