Page 7 - 1987_BALLY_ASPIRE

TOP PLAYFIELD ASSEMBLY W/PLASTICS ...PARTS LISTPART NO. AE14-00004-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
1 AE14-00011-0000 SCREENED PLASTICS SET W/BUSHING
OE14-00901-00XF BUTYRATE: SCREENED DIE-NUT
2 AE18-00018-000 CLEAR PLASTICS SET W/BUSHINGS
OE14-00902-0000 BUTYRATE: CLEAR
3 AE14-00024-0000 SPINNER & GATE ASSY.
AE14-00023-00XF SPINNER & WIRE ASSY.
0017-00104-0084 WASHER .075" - .250" - .062" FL-B NYLON (2 REQ'D.)
0360-00926-0000 WIRE FORM: SPINNER TARGET
0627-00148-0000 BRKT: TARGET-HOLDER
4 AE14-00025-0000 SPINNER & RIGHT GATE ASSY.
0017-00104-0084 WASHER 075" - .250" - 062" FL-B NYLON (2 REQ'D-;)
0360-00926-0000 WIRE FORM: SPINNER TARGET
0365-00146-0000 WIRE FORM: GATE
0627-00148-0000 BRKT: TARGET HOLDER
5 AE14-00027-0000 SPINNER & CENTER GATE ASSY.
AE14-00021-0000 TARGET HOLDER ASSY.
AE14-00029-0000 SPINNER WIRE ASSY: W/TARGET
0010-00275-0265 SPRING: EXTENSION
0017-00104-0084 WASHER .075" - .250" - 062" FL-B NYLON (2 R[Q' D.)
0360-00926-0nOO WIRE FORM: SPINNER TARGET
6 AE14-00038-0000 PLATE TO ENTRANCE RAMP ASSY.
AE14-00042-0000 BACKBOARD ASSY: PLAYFIELO (INCLUDES ITEM.5 7 THRU 11).•.
7 SEE COMMON SOCKET PAGE
8 OE14-00103- 0XF BRKT: GUSSET (2 REQ'D. )
