Page 21 - 1987_BALLY_ASPIRE

TOP PLAYFIELO ASSEMBLY W/PlASTICS - PARTS LISTPART NO~ AE52-00004- 000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
1 AE52-00011-00XF SCREENED PLASTICS SET W/BUSHING
OES2-00901-00XF BUTYRATE: SCREENED DIE-CUT
AES2-00021-0000 BACKBOARD ASSY. : PLAYFIELD (INCLUDES ITEMS 2 THRU 8)
2 AE52-00013-0000 DROP TARGET ASSY. (3 POS. ) (SEE COMMON ASSY. ) (2 REQ 1 D. )
3 AE52-00032-0000 WIRE FORM ASSY. : ACTUATOR RT.
OE52-00112-0000 WIRE FORM: ROLOVER RT.
4 AE52-00038-0000 BACKBOARD CABLE ASSY.
5 A360-00061-0000 SWITCH ASSY.
6 0017-00041-0653 FLIPPER- UBBER 3" YELLOW (2 REQ'O.)
7 OB42-00102-00XF BRKT. : BOTTOM ARCH (2 REQ' O. )
8 OE52-00109-00XF BRKT. : GUSSET (2 REQ'D. )
9 SEE COMMON SOCKET PAGE
10 AES2-00030-0000 RAMP - NETWORK ASSY.
11 AA40-00034-0000 GATE & WIRE ASSY.
OA40-00909-0000 WIRE - FORM: GATE
0370-00116-0000 BRKT. : GATE
12 AE52-00016-0000 SPINNER & GATE ASSY.
AE52-DOOI7-00XF SPINNER & WIRE ASSY.
0017-00104- 084 WASHER .075 ..• .250 ..• .062 FL-B NYLON (2 REQ' O. )
0360-00926-0000 WIRE-FORM: SPINNER TARGET
0627-00148-0000 BRKT. : TARGET .•.HOLDER
13 A331-00042-0000 WIRE ACTUATOR ASSY. (3 REQ'D.)
0360-00135-0000 BRKT. : ROLLOVER WIRE LT.
