BOTT0f01PlA YF I ElO ASSEMBLY - PARTS IIST, CONTI 0 •
PART NO•. AE14-00004-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
A360-00055-0000 SWITCH ASSY. : BALL RETURN
16 SEE COMMON SOCKET PAGE
17 AA17-00027-0000 SWITCH, DIODE & CAP ASSY. : (2 REQ 10.)
A967-00019-0000 TARGET & SWITCH ASSY.
18 AB38-00026-0000 SWITCH, DIODE & CAP ASSY. : RIO WIRE (3 REQ'D. )
A360-00065-0000 SWITCH ASSY.
19 A331-00042-0000 WIRE ACTUATOR ASSY. (2 REQ1D.)
0360-00135-0000 BRKT: ROLLOVER WIRE - LEFT
0360-00929-0200 WIRE FORM: ROLLOVER LEFT
20 A360-00216-0000 WIRE ACTUATOR ASSY. : RIGHT (5 RE01D.)
0360-00134-0000 BRKT: ROLLOVER WIRE
0360-00930-0000 WIRE FORM: ROLLOVER - LEFT
21 A360-00230-0000 SWITCH & BRKT. ASSY. : SLINGSHOT ASSY. (2 REO'D. )
A360-00069-0000 SWITCH ASSY.
22 A360-00239-0000 SWITCH & DIODE ASSY. : SLINGSHOT ASSY. (2 REQ'O. )
A360-00069-0000 SWITCH ASSY.
23 A360-00245-0000 SWITCH & OIOoE ASSY. (-3 REO I O. )
A360-00058-0000 SWITCH ASSY.
24 A360-00245-0100 SWITCH, DIODE & CAP ASSY. (CENTER SPINNER TARGET)
A360-00058-0000 SWITCH ASSY.
25 A360-00603-0005 SWITCH, DIODE & CAP ASSY. - TARGET (YELLOW) (4 REO'O. )
A360-00029-0000 SWITCH & TARGET ASSY.
26 A365-00035-0000 SWITCH, DIODE & CAP ASSY. : RIO WIRE (4 REQ'D.)
A360-00069-0000 SWITCH ASSY.
