Page 11 - 1987_BALLY_ASPIRE

TOP PLAYFIELD ASSEMBLY WID PLASTICS - PARTS LIST
PART NO. A£14-00004-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DESCRIPTION
1 A360-00234-0000 TOP MTD. KICKER ASSY. (BAL RETURN) {SEE COMMON ASSY.}
2 AB42-00036-0000 GATE & WIRE ASSY.
OB42-00913-0000 WIRE FORM: GATE
0391-00916-0000 BRKT: GATE L = 1-7/16"
3 AE14-00013-0000 WIRE GATE ASSY.
0017-00104-0084 WASHER: 075"-.250"-062" FL-B NYLON {2 REQ' D. }
0360-00132-0000 BRKT: GATE
0360-00926-0000 WIRE FORM: SPINNER TARGET
0365-00146-0000 WIRE FORt4: GATE
4 AE14-00014-0000 BALL GUIDE ASS¥. "RIGHT OUTSIDE RAMP"
5 AEI4-00017-0000 BALL GUIDE ASSY. "-LEFT OUTSIDE CHUTE"
6 AE14-00037-0000 THUMPER BUMPER CAP ASSY. STAMPED (3 REQ'D.)
AEI4-00043-0000 FLIPPER PLATFORM ASSY. (INCLUDES ITEMS 7 & 8)
7 AC70-00022-0200 FLIPPER ASSY: SINGLE SW-LEFT (SEE COMfl'10NASSY.)
A365-00045-0000 FLIPPER BREAK SWITCH ASSY.
8 OEI4-00506-0000 PLATFORM: FLIPPER PLAYFIELD: WOOD
AEI4-00044-0000 EJECT - PLATFORM ASSY. (INCLUDES ITEMS 9 THRU 15)
9 A331-00035-0000 EJECT HOLE ASSY. (SEE COMMON ASSY.)
10 SEE COMMON SOCKETS PAGE
11 OE14-00507- 000 BALL-EJECT PLATFORM
12 0017-00042-0390 LIGHT SHIELD: RED: L=I-1/6"
13 0360-00147-00XF BALL STOP BRKT.
14 0360-00733-00XF BUMPER POST (NICKEL)
15 0360-00738-01XF STUD: #6 X 1-11/16" (5 REQ'D.)
16 AEI4-00501-00XF PLAYFIELD & INSERTS SCREENED & PIERCED
