TCP M)UNTED KICKER (BALL RETURN) ASSEMBLY - PARTS LIST
PART NO. A36O-00234-0000
ORDER BY PART NUMBER ONLY
ITEM PART NO. DES~IPTI~
1 A360-00013-0000 CORE Pl.UG ASSY.
2 A360-00044-0000 COIL & TUBING ASSY.
103E-000 2-0015 IN4004GP 400V lA DIODE
3 0.360-00901-0 00 FISHPAPER INSULATOR
4 0010-00274-0189 COMPRESSION SPRING
A.360-00278-000 PLUNGER & LINK ASSY. (ITEMS 5, 6, & 7)
5 0360-00735-00XF PLUNGER
6 0017-00007-0073 ROLL PIN
7 0360-00941-0000 KICKER LINK .
8 0017-00100-0116 RING RER .218 if DIA. (2 REQ'D)
9 A360-00036-0000 KICKER ARM ASSY. (BALL RETURN) .
10 0017-0042-0346 STRIKER RING :
I
1
11 A360-00037-0000 BASE PLATE ASSY.
'12 0017-00007-0124 COT ER PIN J
