DROP TARGET ASSEMBLY
A-3944-0000 Starburst
Ar~944-0003 Red Bu lls Ey e
A-3944-0004 Blu e B ulls E ye
ENDPLATE_
371-125-XF
SPRING
10-279-314
SIDE PLATE
371-123-'0
Generic
DROP TARGET
(See Game Manua l·For
, Specific. DroD T" "rnets)
LATCH PLATE ....,..~
967-144 - 0
COil BRACKET
360-122-XF
SHAFT
360-723
ADJUSTABLE
AND
STATIONERY
_-----_ BOTTOM PLATE
967-142 -q See Bott on Chart
967-143-0
LINK
360-1 8
DROP TARGET
SWiTCH(ES)
A360-62 0 ",See Panel Chart for Glme for correct
dash number Ind quantity required.
CLIP RING
17-100-117
SIDE BY SIDE DROP TARGET ASSEMBLV
NQ. of Drop T• .,.... Adjusubl. Stationery'
InAsMmb ty A.-B. Bot tomP". Bottom PII'I SidaPIIta Latch Plat. Shift
3 371-103-X F 967-142-3XF 967~143-3XF 371-123 ....12XF 967-144-W 360-723-1XF
4 370-144-XF 967-142-4XF' 967-143-4XF 371-123-13XF 967-144- 360-723-2XF
5 967-141-XF 967-142-5XF 967-143-5XF 37L ..123-14XF 967-144,.1JXF 360-723-3XF
6 390 .•..101-XF 967-142-6XF 967-143-6XF 371-123-15XF 967-144~6XF 360-723-4XF'
7 967-128-XF 967-142-7XF' 967-143-7XF 371-123-16XR 967-144 7XF 360-721-5XF
WHEN ORDERINGPART. SPfCIFY PART 10. lID OlE OF 6AIE
