MOuNTING SCREWS
(4 Aeq'd)
R LPP,832-" 804
ROTATiNG SelECTOR SWITcH BALLSPINNER & MOTOR ASSV.
(6 Req'd) ASE·3212
ASW'A 1-229
SWITCH SPRING PLATE
(5 Reo'd)
P-137-51
SWITCH INSULATOR
(5 Req'd)
P-150·199
CABLE
E-556·966
ASSEMBLY MOUNTING BRACKET!
P·6629·211
SWITCH MOUNTING SCREWS
(10 Req'd)
RlPP·540-1808
SWITCH DIODE
(4 Heq'd]
E-587-14
MOUNTiNG BRACKETS
{2 Req'dl
P-6665·794
MOTOR MOUNTING SCREWS
(4 Req'd)
MOTOR LSPR·832·1108
E·119·512
DISC AND SELECTOR ASSV.
ASE-3215
DISC AND BUSHIN,G ASSY.
A·4097
SPINNER BALL INDEX SWITCHES
(12 Req'dJ
ASW·Al·227
SWITCH MOUNTING SCREWS
(24 Req'd)
(Not Shown)
MSSR·348·1106
SPACERS
(4 Req'd) ---~~___ :~ 'c- -~~--..;:;::;,r..u::.
(Not Shown)
8·231·924
P.C. BOARD MOUNTING SCREW
13 Req'd)
MSSF·348·1108
COPPER FLASHED MOUNTING SCREW
MSSF·348·1112 PC. BOA'RD (Rotating Selector)
p'..2948-491
92 WHEN ORDERING PART'. SPECIFY PART NO. AND NAME Of G'AME
