DROP TARGET ASSEMBl Y
AS -2795- 0
RESET LINK
P1973 -418 ADJUSTABLE
AND
STATIONERY
BOTTOM PLATE RESET BAR
,---------- -, P-8173-D P-794 4-0
P·8174 -D
SIDE PLATE
P-1445"D DROP TARGET
A-3994·D
END PLATE _
P-1369-6
SPRING
SP-,0()·314
LATCH PLATE
P·1370-D
END PLATE
P·1369·S
CORE PLUG & BRACKET
....----- A·613·99
COIL
(Refer to Panel lo r Game)
.COll BRACKET
P·2236-20
DROP TARGET
SWITCHfES)
ASW-Al-168 0 '" See 'Panel Ohart for Game for correct
dash number and ouantitv required.
CLIP R.ING
P·'5829·2
..
No. of Drop·Targa-ts Adjustable Stationary
,I
in Assembly Reset. Bilr Bottom Plate Bottom Plate Side Plate la tch Plat'1 Shaf t
3 P·7944·2 P-8173-3 P-8174·3 P-1445·12 P·1370-13 .S-739-2.11
4 P-7944-, P-8173·4 P-81744· P-·1445-13 P,1370·14 8-739-272
5 P-7944- P·8173·5 P·8174·5
[
P-1445-14
1
P;U70·15 8·739-273
6 P-7944-6 p,817a-Q P·8174-6 P-1445-1.5 P-1370-16 5-739-274
7 P-7944-3 P-8173·7 P.8174·-7 P-1445-16 P-1370·17 5-739-.275
SIDE BY SIDE DROP TARGET ASSEMBLY
86 WHEN ORDERING PART. SPECIFY PART NO. AND NAME OF GAME
