R1, R3, R5, R7, R9, Rl1, R34
Resistor, WOK
4
R14, A16, R18, R20, R22,
Resistor, 300K
R24, R26, R35, R36, R37,
R38, R39, R40
5
R43, R44, R45, R46, R47, R4B
E-105-228
Resistor, 9_
i
K
6
R13, R15, R17, R19, R21,
E-105-229
Resistor, 1.5K
R23, R25
7
R27, R28, R29, R30, R31,
E·105-222
Resistor,
L2K
R32, R33
8
R41
E-105-231
Resistor, 39K
9
R42
E-l05-271
Re-sistor, 240K
10
11
Cl, C2
E·586-65
Capacitor, .01 MFD
13
07,08,0 9,010 ,011, Q12
1:-585.32
Trarrslstor (2N54G1)
14 01, Q2, 03, 04, 05, 06, 013,
E·585·33
T ransistor (MPS-A4 2)
014, Q15, 016, 017, 018, 019
16 VRl
E·598-7
Zener Diode, 110V
17
Ul
E-620·38
I,C. Decoder
18
19 Jl
E736-10
10 Pin Wafer Pin Connector
21 OS1
E-680
Digital Display Panel
22
M-1836
Hi-Lo Screw, W/H
23
P·2399
Display
Mounting
(Top)
24
P-2399·1
Display
Mounting
(Bottom)
26 R2, R4, R6, R8, R10, R12
E-105-287
Resistor,
2 ..2K
27
R49, R50, R51, R52, RS'3, R54
E·105·242
Resistor, 20K
28
WireJumpe~
NOTE: INTERCHANGEABLE WITH AS-2518-15
