COMPONENT PARTS LIST
1
2
3 A2
4
5
6
7
8
9
10
11
1213
14
15
i6
17'
18
19
20
21
Power Transformer Module,
Complete
A$·3071-7 Transformer
E-148-25 Fuse Holder
AS-2518-54 Power Module Assv,
M·1829·4 Hinged Support
M·1829-3 Edge Holder
M-1829-5 Spacer
p·6442·244b Fuse & Connect Br ket.
P·6A42'-312 Chassis
RLPP·832·1114 Screw
RLPP·, 032·18.06 Screw
P,2692-2 Shi eld
M-469-936a High Vorlage Sticker
E-133.24 3A 5.6. Fuse
M-1834 H. S. Compound
E·120-120 Socket
E·4 11 ·7 Starter
R'lPP·832-1B04 Screw
EA09-1 Ballast
R LPP -632-1 B04 Screw
PW-l0·12 Washer
EB04-6 Connector
NOTE : Items 15-21 are used on AS·2877·9 Power Transformer Module for
Mr. & Mrs. PAQ_M8.N only . R . OR
NOTE 2: E.LEKTRA, Mr.&Mrs _ PAC MAN . SPECT UM, and VECT
have a lamp flashe r triac moun ted to the transformer base plate.
The lamp flasher triac part number is E-585-67, vendor part numbe r
MAC-38-2 .
