v 000 ~
A. R-521 3/4" Dia. (2)
B. R-521-1 1" Dia. (5)
~
C. R-521-2 1-112" Dia.
D. R-521-3 2" Dia. (2) °0 E. R-521-4 2·1/2" Dia. (3)
F. R-521-5 3" Dia. ( 1)
~~O
G. R-533·3 Lower Flippers
PANEL TOP PARTS
= ~ 7 = <"::",B
======= ',.) 22
10 o
@ogo@~~
[ 14 1
'1
08 c::::=
22 IT c:::J::=
O~
ai> 0
15 0
• 0
o
o
o 15•
BACKGLASS
G-440·18
19
i'5~ I
~W
2
WHEN ORDERING ' PART, SPECIFY PART NO. AND NAME OF GAME
46
RUBBER PARTS
Dimensions are inside diameters. Numbers in
parentheses indicate quantity used, if in
excess of one.
1. Bottom Arch . . . . . . .. P-5871-87
2. Shooter Gauge P-6359-52
3. Gate & Wire Assy ..•... ASE-2250-24
4. Gate & Wire Assy ..•... ASE·2250-94'
5. Gate & Wire Assy ASE·2250-95
6. Spinner Assy ASE·2250·96
7. Feature Display Assy ASE-3114
8. Target Switch Assy. . .. ASE-2911·57
9. Bumper Cap A·4009·6
10. Bumper Collar C-l018-1
11. Guide Wire M-121·118
12. Guide Wire M-121-117
13. Guide Wire . . . . . . M-121-116
14. Playfield Readout Cover M-1949-1
15. Minipost & Bumper Assy. ASE-2836·2
16. Minipost & Bumper Assy. ASE-2836-3
17. Large Transparent FI ipper A-4017-1
18. Buffer Wire M-121-53
19. Rollover Button ....•. C·900
20. Wire Actuator ASE-2806
21. Wire Actuator ASE-2806-1
22. Screened Plastics ASE-2890·159
23. Panel CAS-1128-191
24. Playfield Overlay M-1787-44
25. Outhole Wire & Bracket. ASE-2806-21
WHEN ORDERING PART,
SPECIFY PART NO.
AND NAME OF GAME
47
