~\I:========-
~
~'~rdse\IGermanV)EcI26'83
COld Se1 (Japan) E 12667
Cord Set (Cah l I E 126 75
Cord Set IDome~ tic) E 12663
Cord Se1 (France) E·126-90
Cord Set
(Au$1Ialial
E-126·91
220V VARISTOR
E-713-1
KNOCKER
AS ·2404·12
ASW·A1Q-41
TILT BOARD
ASSEMBLY
AS-2845·5
TILT SWITCH
ASW,AO·5
(N 01
Shown)
E-138-3
o
SWITCH ASSEMBLY IDENTIFICATION NUMBERS
Refer to Page 61
Plug Connectors Charts
1. lnline Drop Target A (Top)" .. ,
,ASW·A 1·168
2, Inline Drop Target B . ,
, .. , , .. _ .. ,ASW-A 1-168
3. InlineDropTargetC
,
",
. ASW·Al-168
4. Inline Drop Target 0 (Bottom) .. , .. , , , ,ASW·A 1-168
5.
Inline Back Target,
,
A-3359-15
6.
7.
Tilt
:
,
ASW-A1-145
8. Outhole
, ,
ASW-A1·143
9.
10.
11.
12, A Rol lover
ASW-A 1-206
13, B Rollover
ASW·A 1-206
14. C Rollover
ASW-A 1-206
15.
0
Rollover
,
ASW-A 1·206
16.
17. 1,9 Drop Target. ,
ASW-A l·168
18. 2,10 Drop Target
ASW-Al-168
19. 3, 11 Drop Target
ASW-A '·168
20.
4,12D ropTarget
ASW-Al·168
21. 5,13 Drop Target
ASW·A 1-168
22.6,14 Drop Target
ASW-A1-168
23.7, 15 Drop Target
ASW-Al·168
24. 30 Point Rebound
ASW-A 10-47
25.
0
Targe t
A·3359- 20
26. 1st
E
Target
,
A-3359-20
27. L Targe t
A-3359-20
28 . U Target
A-3359-20
29. X Target
_
' _
A-3359-20
30. 2nd E Target
_ A-3359 -20
31. RightOutlane
_
ASW-A1-206
32. Left Outlane
ASW·A 1-206
33. Single Drop Target
,
ASW·Al·168
34. Saucer
,. ,
,ASW-A1- 187
35. Rollover Button
ASW-Al-152
36. Right Sling Shot _
ASW-A 10-47
37. LeftSlingShot
,
ASW-Al0-47
38. Lef t Thumper Bumper
_ . ASW-Al-195
39. Right Thumper Bumper
_
_ ASW·A 1-195
40. Bottom Thumper Bumper
ASW-A 1-195
o
SOLENOID AND COIL IDENTIFICATION NUMBERS
PLUMB BOB WI RE
M,ll5
FLIPPER SWITCH
1. Left SIing Shot
,
AN-26-1200
2. Right Sling Shot,
AN-26-1200
3_ Knocker
_
AR-26-1200
4. Left Thumper Bumper
AN-26·1200
5. Right Thumper Bumper
AN-26·1200
6. Bottom Thumper Bumpe r
,
AN-26 -1200
7. Single Drop Target
AO-27-1300
8.
1,
9
Drop Target
CV-31-2000
9.
2, 10 Drop Target
CV-31-2000
10. 3, 11
Drop Target .. ,
CJ-31-2000
11.
4, 12 Drop Targe t
CJ·31-2000
12. 5, 13 Drop Target
, .. CJ·31-2000
13. 6,
14
Drop Target
CJ-31-2000
14. 7,15DropTarget
,
,
,CJ-31·2000
15.
7
Drop Target Reset
NB-26-1900
16.
4
Drop Target Reset
,
NB-26-1900
17. Saucer
_
AT-27·l300
18.
Outhole Kicker
AT·26·1200
19. Coin Lockout Door
FO-36-7000
20. FIippers . . . . . . . . . . . . . . . . . . . . AQ-25-500/34-4500
~ ASSEMBLY IDENTIFICATION NUMBERS
PANEL BOTTOM PARTS
P-7750
1.
Eject Hole Assembly
ASE·428-53
2_ Right Flipper
ASE-1587 ·111
3. Left FI ioper
, .. ASE-1587 -112
4.
Upper Left Flipper _ . ,
, _
ASE-1587-118
5. Left Slingshot
,
ASE-2593 ·6
6.
Right Slingshot
ASE-2593 ·6
CAPACITOR
E·586·19
TILTHANGER
P·7783
7. Inline Drop Target
ASE·2993-12
8.
Single Drop Targe t
,
_
ASE·2993· 14
9. Left Thumper Bumper
,
ASE-2999
10. Right Thumper Bumpe r
, .. _ .. _ ASE-2999
11. Bottom Thumper Bumper
ASE·2999
12. 7 Memory Drop Target
'
ASE-3038-3
60
WHEN ORDERING PART. SPECIFY PART NO. AND NAME OF GAME
WHEN ORDERING PART
I
SPECIFY PART NO. AND NAME OF GAME
