Page 43 - 1980_BALLY PARTS ASPIRE

SEO Version

SILVERBALL MANIA
o
SWITCH ASSEMBLY IDENTIFICATION'
NUMBERS
1. Bottom Center Lane
,
ASW·A1·197
2. Hoop R.O. Button (2l
ASW·Al·162
3. Top Right Rollover ..............•..
ASW-A1·155
4. Top Center Rollover
.ASW-A1-155
5. Top Left Rollover ..•...............
ASW-A1-155
6.
7. Tilt ........................•...
ASW·A.'·l45
8. Outhole Kicker ...••........••.....
ASW-A
1-143
9.
10.
ll .
12. Top Bumpers (4)
, .. ASW-A110-6
13.
14.
15.
16.
17. Right "A" Target
_
A-3359-20
18. Left
"B"
Target
A·3359·20
19. Left
"Rn
Target .•.•.
,....•.........
, A·3359·20
20. Left "E" Target . ,
A·3359-20
21. Top "V" Target ...•.•..............
A-3359-20
22. Top
" L"
Target
,
A-3359-20
23. Top "I" Target .........•....•.
_ ...• A-3359-20
24. Top "5" Target ........•...
, . , , ,
A-3359·20
25. Right Spinner ..........•.....
,
ASW-A
1-151
26.
"AN
Right OUt Rollover
ASW-Al-155
27. Right "I" Return R.O...••....•......
ASW·Al·155
2.8. Center Target
A-3359-20
29. "An Left Heturn R.O
ASW-Al·155
30. "M" Left Out R.O.. , .. "
ASW-A1-155
31. Lower "L" Side Target
A-3359·20
32. Upper "L" Side Target .......•........
A-3359-20
33. Left Spinner ..............•..•....
ASW-A'·151
34. 50 Pt. Rebound (4)
,
ASW-Al0-47
35.
Service
Sw.
(Panel) ..•..•.•...•........
E·658·2
36. Ri,ght Slingshot .....•••
,
ASW·Al0-47
37. Left Slingshot •...
,
ASW·A10·47
3B,
Center Thumper Bumper ...•....•....
ASW·A110·5
39. Right Th
umper Bumper •..
A • • ••
, ~ • • • • •
ASW·A110·5
40, Left Thumper Bumper
ASW·A110·5
D
SOLENOID AND COIL IDENTIFICATION NUMBERS
1.
Outhofe Kicker ..•.........
, ......•
AN-26-1200
2.
Knocker .....•......•••..•.•..•
,
AR-26·1200
3.
Kick
and Down .•................
, • AN·26-1200
4. Right Slingshot
,
AN,26·1200
5. Left Slingshot .........•..
'
AN·26·1200
6. UP Kicker
, . . . . . . . . . . , , . . . NO·26·l200
7. Left Thumper Bumper
, . , ....•....
AN-26-1200
B. Right
Thumper
Bumper
_
AN·26-1200
9.
Center Thumper Bumper •.•...
_ .•.•..
AN·26-1200
10.
Coin Lockout Door ..•........ ......
FO·36-7000
11.
Flippers
AQ.2S-500/34-4500
~ ASSEMBLY IDENTIFICATION NUMBERS
PANEL BOTTOM PARTS
1. left
Thumper .. , ......•.•...
, ,
ASE-1567-13
2.
Center
Thumper
,
ASE-1567-13
3. Right Thumper ....•..•...•.......
ASE-1567·13
4. left Slingshot
ASE·2593-4
5. Right Slingshot ..•.......••...
,
ASE·2593·4
6. Left Flipper, .. ,
ASE·1587·101
7. Right Flipper
, . ,ASE·1587·102
a.
Disappearing Kickback
ASE·3007·'
WHEN ORDERING PART,
SPECIFY PART
NO.
AND NAME
OF
GAME
43
