Page 41 - 1980_BALLY PARTS ASPIRE

SEO Version

SILVERBALL MANIA
A. R·521-1
1" Dia.
(3)
B. R·521~2
1-1/2"
Dia.
(2)
0
C. R·521-3
2" Dia.
(1 )
D. R-52~-4
2·1/2"
Dia .
(4)
E. R-406-3
FLIPPER
(2)
F.
R-243
5/16" Dia.
(14)
o
o
o
o
o
o
5
o
B
0 0 00
0000000000
0000 0
o
0
o
o
29
r- • .•
22
r'"
RUBBER PARTS
Dimensions are inside diameters. Numbers in
parentheses indicate quantity used, if in
excess
of one.
PANEL
TOP PARTS
1 .
Arch
Rail.
M-1774
2. Rail
Post
C·907
3.
Rail
Post Cap
C·908
4.
Bottom Arch
,P-5871-72
5.
Shooter Gauge
P·S359-38
6.
Ball
Rebound Assy .....•
AS-49a.6
7. Ball Gate Assy
A-1475-13
8.
Screened
Plastic
Set. . . .
.M·1330-159
9.
Bumper Cap
(4) . .", _ ..
.A-3852-1
10.
Thumper Bumper
Cap (3) .A-3713-59
11.
Ball
Guide Wire (6) .....
M·121-32
12. RollOVer Wire Assy. (7) ..
AS·280S
13.
Target
Assy . (yellow) (11) AS-2911 e2l
14. Ball
Guide Wir.e
M·121-30
15.
Ball
Gate
&
Wire
AS-2250-24
16. Spinner
Gate
Assy
AS·2250-S1
17. Spinner
Gate
As.sy. .
AS-2250-62
1
B.
Ball Gu
ide Assy
A-3032-34
19.
Ball
Guide Wire (2)
M-121-24
20. Ball
Guide
Wire
M-121-78
21.
Ball Guide
Wire
M·121-79
22.
OutholeWire&Brkt.
Assy. ASE·280&-21
23. Ball Guide Wire •.....•.
M-121-91
24.
Ball Guide
Wire
M·121-92
25.
Flipper &
Shaft Assy. (2)
.AS,2214-24
26. Mini·Post Assv. (8)
AS~2836-1
27. Bumper Body (4)
ASE-2222·S
28. Thumper Body (3)
ASE·2222-4
29. Ou thole
Kicker
ASE·2694-3
30. Protective
Angle
P·7639
31.
Panel. . , , . ,
CA·1128·172
WHEN ORDERING PART.
SPECifY PART NO.
AID NAME OF GAME
41
