-8Alt .¥-
tTlM.
PAfU NO.
1 AS (see note
1)
E·3022·1
PWB Module- Complete
2
Ul
E·620·124
Sound Chip AY·3·8910
3 U2
E·620·29
PIA, S820/2,1
4 U3
E·620·125 (1:620·128)
CPU, 6802 (S802 Note 1)
5 Ul0
E-620-30
Ram, 68,10 (Note 1)
6 U5
E·S20·33
Hex Inverter 4049B
7 U6
E~620·5
Quad 2 Input 4011 B
8 UB
E·620,126
Amp, LM39QO
.9
U9
E·62Q·127
Power Amp, TDA 2002
10
Q1
E·585·31
Transistor,2N3904
1 T
CR1,2
E·687·6
Diode. 1N4004
12 SW1
E-658-1
Switch
13 C12
E·586·118
Cap .. 2MF
±
20% Y5P, lBV,
14 C2
E·58S·119
Cap .. 0068 UF ±20% Z5U, 1K
15 C16
E·58S·S3
Cap. 470 ~F 50 V.
16 C3
E·586·120
Cap. 68 PF,
±
20% 1 K
17 C18,19
E·SS6·121
Cap. 27 PF,± 20% lK
18 Y1
E·144·5
Crystal, 2.579545 MHZ
19 J2
E·736·2
Connector, Water, 2 Pin K K 156
20 Jl
E·736·1S
Connector, Wafer, 15 Pin KK156
21 R9
E·l05·196
Resistor, 1 Ohm,
Y.
W., 5%
22 R8
E·l05·211
Resistor, 2.2 Ohm,
Yo.
W., 5%
23 R7
E·10S·303
Re~istof. 220 Ohm,
%
W., 5%
24 Rl
E·105·230
Resistor,l
K,
%
W., 5%
25 R2l, 22,23,24
E·105·238
Resistor, 3.3K. Ohm,
v..
W., 5%
26 R6
E·105·239
Resistor, 4.7K.,
%
W., 5%
27 R3, 14, 15. 16,
17,18,19,25
E·105·185
Resistor. 10K,
v..
W., 5%
28 R2
E· 105·245
Resistor, 30K,
Yo.
W., 5%
29
R10
E·105·252
Resistor, 180K.,
Y.
W., 5%
30 R4
E·l05-225
Resistor., ,200K" '% W., 5%
31 R5,20
E·l05-285
ReSIstor, 1M,
%
W., 5%
32 RT1
1:·599~16
Potentiometer 1K
33 C23
E·S86·122
Cap .. 001±20%2S F
34 C15
E·586·t23
Cap. 4700 MF
@
25 V.
35 C7
E_·586·124
Cap. 470MF @6V.
36 C8
E·586·125
Cap. 220MF@ 25 V.
31 C5,13
E-586·90
Cap. 1 M F
@
50 V.
38 C9,1, 14,6
E-S8S-89
Cap .. ' MF
39 C4, 22,17,21,
20,24
E·586·85
Cap .. 01 MF
40 XU10, XU4
E·712
Socket, 24 Pin
41
XU1, XU2, XU3
E;712-1
Socket, 40 Pin
42 Used with 43
LSPR-00632·1106
Bolt, 6 x 32 x 3/8
43 Used with 42
N·OO632·2112
Nut, 6 x 32
44 H.S for U9
E·682·8
Heat Sink, 6030an
45 Used with C 15
£:·647·5
Ty Rap
46 TP1, 2,3,4,5.,6
P·53S9
Test Point
47 Use with 44, 9
M·T834
Thermal Grease
48
Jumper, B
22 AWG Wire, Solid Tinned
W·1211C
Schematic
NOTE 1. When ordering specify name of game.
NOTE
2:
Order replacement memory chi p U4 specifying name of game and part no, stamped on chlp.
