MOUNTING BRACKET
A-643-7
BALL KICKER
ASSEMBLY
A-642-6
SAUCER HOLE
KICKER ASSEMBLY SHAFT
AS-428-40 S-181 -48 RET AI N I NG
RING
P-631
RETAINiNG
RING
P-6316-4
{Not Shown}
M-1721-7
CORE PLUG
ASSEMBLY
A-613-30 SPRING
SP-l00-230
COIL
REFER TO PANEL CHARTS
BRACKET &
SPRING HOOK
ASSEMBLY
A-642-7
TOP MOUNTED BALL KICKER
AS-2694-3
CORE PLUG ASSEMBLY
A-613-89
COIL
REFER TO
PANEL CHARTS
PLUNGER &
LINK ASSEMBLY
ASE-2586
COMPRESSION SPRING
SP-200-189
KICKER ARM ASSEMBLY
BALL RETURN
A-3545
STRIKER RING
C-838
BASE PLATE ASSEMBLY
A-3546
WHEN ORDERING PART, SPECIFY PART NO•. AND NAME OF GAME WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
14 75
