Page 10 - 1980_1_PARTS_ASPIRE

DROP TARGET AND MEMORY COIL ASSEMBLY
ASE·3038·D
DROP TARGET ASSEMBLY
ASE-2795·D
(SEE PAGE 77 FOR PARTS BREAKDOWN)
COMPRESSION SPRING
SP-200-206
COMPONENT PARTS LIST
PLUG BUMPER
R-231-11
1 Rectifier Board Assembly,
Complete
3 R1 E-OO104-0092 Resistor, 10%,600 Ohm, lOW PLUNGER ASSEMBLY
4 R2 E-00104-009l Resistor, 25 Ohm, 5W A-555-S
5 R3 E-OO105-0226 Resistor, 5%, 100K Ohm, Y..W
7 VRl E-00623 Varistor
9 CRl, CR2, CR3, CR4 E-00587-0006 Diode (IN4004)
12 SA 1, BR2, BR3 E-00602-0003 Bridge Rectifier (VJ248 VARO)
14 Fl E-OO133-00 10 Fuse, lOA, 32V, 3AG
15 F2 E-OO133-002S Fuse, 3/4A, 250V, 3AG,
16 F3 E-00133-0004 Fuse, 4A, 32V, 3AG
17 F4 E-00133-0005 Fuse, 5A, 32V, 3AG
18 F5 E-00133-0027 Fuse, 20A, 32V, 3AG
19 F6 E-00133-0024 Fuse, 3A, 3AG, SoB.
21 E-00684 Test Point
22 J1 E-00736-000S S Pin Wafer Connector
23 J2,J3 E-00736-0010 10 Pin Wafer Connector
25 E-00148-0021 Fuse Clips
26 E-OO148-0022 Fuse Clips
c c MEMORY COil ASSEMBLY
ASE-3013
WHEN ORDERING PART. SPECIFY PART NO, AND NAME OF GAME
