o SWITCH ASSEMBLIES
rap Target E (Bottom) AS-2911·24
2. Drop Target D AS-2911-24
3. Drop Target C AS-2911-24
4. Drop Target B AS-2911.24
5. Drop Target A (Top) AS-2911-24
6. Credit Button ASW-A 10-46
7. Tilt (3 ). AS-2911-2
B. Outhole AS-2911-7
9. Coin III (Rt.) AS-2744-9
10. Coin I (Left) . . . . . . . . . . . . . . . . . . . . . .. AS-2744-9
11. Coin II (Middle) AS-2744-9
12.
13.
14. Right Outlane AS-2911.9
15. Left Outlane AS-2911-9
16. Slam (2) ASW-A20-32
17. Top Right Lane AS-2911-9
1B. Top Left Lane AS-2911-9
19.
20. Spinner Right AS-2911-11
21. Spinner (left) AS-2911-11
22. Left Bottom Target AS-2911-19
23. Left Middle Target AS-2911-19
24. Left Top Target. . . . . . . . . . . . . . . . . . .. AS-2911-19
25. Down Post R.O. Button (2) . . . . . . . • . . .. AS-2911-25
26. Drop Tar. Reb. . . . . . . . . . . . . . . . . . . .. AS-2911-12
Top A.D. But AS-2911-25
27. Top Right Target AS-2911-3
2B. Top Left Target AS-2911-3
29. Center Target AS-2911·3
30.
31.
32. Saucer . . . . . . . . . . . . . . . . . . . . . . . . .. AS-2911-22
33.
34.
35. L & R Flip/Feed Lane AS-2911-9
36. Right Slingshot AS-2911·4
37. Left SI ingshot . . . . . . . . . . . . . . . . . . . . . . AS-2911-4
38. Bottom Thumper Bumper AS-2911-1
39. Right Th umpe r Bu m per . . . . . . . . . . . . . .. AS-2911-1
40. Left Thumper Bumper . . . . . . . . . . . . . . .. AS-2911-1
D SOLENOID ASSEMBLIES
1. Post Up . . . . . . . . . . . . . . . . . . . . . . . . . GA-3S-2000
2. Outhole Kicker AN-26-1200
3. Knocker AR-26-1200
4. Saucer A0-27-1300
5. Left Thumper-Bumper AN-26-1200
6. Right Thumper-Bumper AN-26-1200
7. Bottom Thumper-Bumper AN-26-1200
8. Left Slingshot AN-26-1200
9. Right Slingshot AN-26-1200
10. Drop Target N0-26-1900
11. Post Down AN·26-1200
12. Gate GA-34-4000
13. Coin Lockout Door FO-36-7000
14. K1 Relay (Flipper Enable) AO-25-500/34-4500
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
