Page 50 - 1979_BALLY_PARTS_ASPIRE

0
~ ~
28 OI~O~'
0 ®
co co
/I 0) ,I 20
e
0022
,,
/ie"
I 4
o
Dimensions are inside diameters. Numbers in
parentheses indicate quantity used, if in
excess of one.
RUBBER PARTS
0 A. R-521-1 1" Dia. (4)
B. R·521 . 3/4" Dia. (2)
C. R-521·6 3-1/2" Dia. (1 )
D. R·521-5 3" Dia. (1)
E. R·521-4 2-1/2" Dia. (2)
F. R·406-3 Flipper (2)
G. R-243 5/16" Dia. (14)
PANEL TOP PARTS
1. Arch Rail M-1774
2. Rail Post (2) . . . . . . . . . C-907
3. Rail Post Cap (2) . . . . . . C-908
4. Bottom Arch P-5871-59
5. Shooter Gauge. . . . . . .. P-6359-25
6 . Ball Gate (L) A-1475-10
7. Ball Gate (R). _ A-1475-9
8. Screened Plastics A-2890-130
9. Thumper Cap (2) _ .. A-3713-38
10. Thumper Cap . . . . . . . . A-3713-39
11. Plastic Guide (2) . . . . . . C-935-1
12. Plastic Guide C-936-1
13. Target Ass'y. (Red) (6) .. ASE-2911-3
14. Minipost & Rubber ..... ASE-2836-1
15. Spinner Gate Ass'y. . . .. ASE-2250-50
16. R.O. Wire & Bracket (6) . ASE-2806
17. Ball Guide M-121-69
18. Ball Guide _ M-121·70
19. Ball Guide (2) M·121·30
20. Ball Guide M-121-71
21. Ball Guide . . . . . . . . . . M-121-72
22. Ball Guide (2) M-121-18
23. Ball Guide M-121-43
24. Ball Guide M-121-44
25. Buffer Wire (2) M-121-53
26. Outhole Wire Ass'y ASE-2806-21
27. Flipper & Shaft Ass'y. (2) ASE-2214-24
28. Rollover Button C-900
CONS. - Conservative
MED. - Medium
LIB. - Liberal
Indicates movable posts for
scoring adjustments.
WHEN ORDERING PART.
SPECIFY PART NO.
AHD NAME OF GAME
51
