Page 48 - 1979_BALLY_PARTS_ASPIRE

SEO Version

o
SWITCH ASSEMBLI ES
1. Top "S" A.O. Lane
AS-2911-9
2.
Top "C" R.O. Lane
AS-2911·9
3.
Top"
A"
R.O. Lane
AS-2911-9
4.
Rt. FI ipper Feeder Lane
AS-2911-9
5.
Left Flipper Feeder Lane
AS·2911-9
6.
Credit Button
ASW-Al0-46
7. Tilt (3)
AS-2911-2
8. Outhote
AS-2911·7
9.
Coin
III
(Right)
AS-2744·9
10.
Co in
I
(Left) . . . . . . . . . . . . . . . . . . . . . . .
AS-2744-9
11.
Coin
II
(Middle)
AS-2744-9
12.500
Side Target
AS-2911-20
13.10Pt.
Rebound
AS-2911-4
14.50
Pt. Rebound
AS2911-4
15.
16. Slam (2)
ASW-A20-32
17 . 1
Pin
AS-2911-25
lB. 2
Pin
_
AS-2911-25
19.
3
Pi
n . . . . . . . . . . . . . . . . . . . . . . . . . ..
AS-2911·25
20. 4
Pin . . . . . . . . . . . . . . . . . . . . . . . . . ..
AS-2911·25
21. 5
Pin . . . . . . . . . . . . . . . . . . . . . . . . . . .
AS-2911-25
22.6
Pin
AS-2911-25
23.7
Pin
AS-2911-25
24 .8
Pin
AS-2911-25
25.
Spinner . . . . . . . . . . . . . . . . . . . . . . . ..
AS-2911-11
26.
9
Pin. . . . . . . . . . . . . . . . . . . . . . . . . ..
AS-2911-25
27.10
Pin
AS-2911-25
28. "E"
Target
AS-2911-20
29.
"H "Target
AS·2911-20
30. "A"
Target
AS·2911-20
31. "P"
Target . . . . . . . . . . . . . . . . . . . . . ..
AS·2911-20
32.
Saucer
AS·2911-S
33.
"S" Target
AS-2911-20
34.
Right Outlane
AS-2911-9
35.
Left Outlane . . . . . . . . . . . . . . . . . . . . . . .
AS-2911-9
36.
Right Slingshot ...................•
AS-2911-23
37.
Left Slingshot
AS-2911·23
38.
Bottom Thumper-Bumper.
. . . . . . . . . . . . .
AS-2911-1
39.
Left Thumper-Bumper
AS-2911·1
40.
Right Thumper-Bumper
AS-2911-1
D
SOLENOID ASSEMBLI_~S
1.0uthole Kicker
AN·26-1200
2. Knocker
AN·26·1200
3. Saucer
A0-27-1300
4 . Tone
10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..
5. Tone
100
.
6. Tone
1000
.
7. Tone
10,000
(Extra)
.
8. Left Thumper-Bumper
AN·26-1200
9.
Right Thumper-Bumper
....•.........
AN·26-1200
10.
Bottom Thumper-Bumper
AN·26-1200
11.
Left Slingshot ...........•.........
AN·26-1200
12. Right Slingshot ..........•.........
AN·56-1200
13. Coin Lockout Door
FO·36·7000
14.
Kl
Relay (Flipper Enable) ..•.....
AQ·25-500/34-5050
