o SWITCH ASSEMBLIES
6. Cred it Button . . . . . . . . . . . . . . . . . ASW-A 10-46
7. Tilt (3) AS-2911-2
8.0uthole AS-2911-7
9. Coin III (Right) AS-2744·9
10. Coin I (Left) . . . . . . . . . . . . . . . . . . . . . . . A~2744-9
11. Coin II (Middle, if used) AS-2744-9
16. Slam (2) ASW·A20-32
17. Rt. Drop Target D (Bottom) ASE-2911-17
18. At. Drop Target C ASE-2911-17
19. Rt. Drop Target B . . . . . . . . . . . . . . . .. ASE-2911-17
20. At. Drop Target A (Top) ASE-2911-17
21. Left Drop Target D (Bottom) ASE-2911-17
22. Left Drop Target C ASE-2911-17
23. Left Drop Target 8 ASE-2911-17
24. Left Drop Target A (Top) ASE-2911-17
25. Right Flipper Feeder Lane AS-2911-9
ASE·2911-4 (3) Switch not shown.
26. Left Flipper Feeder Lane AS-2911·9
27.10 Pt. Drop Target Rebound (2) AS-2911-12
28. Right "8" Lane AS-2911-9
29. Left "A" Lane _ . _ AS-2911-9
30. Top "8" Lane AS-2911·9
31. Top "AU Lane _ . _ AS-2911-9
32. Top Saucer AS-2911-22
33. Right Outlane .........•............ AS-2911-9
34. Left Outlane . . . . . . . . . . . . . . . . . . . . .. A~2911-9
35. Right SI ingshot . . . . . . . . . . . . . . . . . . . . AS-2911-23
36. Left Slingshot ........•............ AS-2911·23
37. Bottom Right Thumper-Bumper AS·2911·1
38. Bottom Left Thumper-Bumper AS-2911·1
39. Top Right Thumper-Bumper AS-2911·1
40. Top Left Thumper·Bumper A8-2911-1
D SOLENOID ASSEMBLIES
1. Outhole Kicker AR·26-1200
2. Knocker AR-26-1200
3. Chime 10 CN-31·2000
4. Chime 100 CN-31-2000
5. Chime 1000 . . . . . . . . . . . . . . . . . . . . . . CN·31-2000
6. Chime 10,000 eN·31-2000
7. Bottom Left Thumper-Bumper AN-26-1200
8. Top Left Thumper-Bumper AN-26-1200
9. Top Aight Thumper-Bumper AN-26·1200
10. Bottom Right Thumper-Bumper AN·26-1200
11. Left Slingshot .....•............... AN·26-1200
12. Right Slingshot .....•.............. AN-26-1200
13. Top Saucer .......•............... AO·27·1300
14. Left Drop Target NO-26-1900
15. Right Drop Target .......•........•. NO·26-1900
16. Coin Lockout Door .••.............. FO-36-70aO
17. K 1 Relay (FI i pper Enable) AQ-25-500/34-50SO
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
