Page 38 - 1979_BALLY_PARTS_ASPIRE

o
o o o o
8 8 o
0
~
• I
~
I B I
I I
I I
I ,..
20
o
26
o 22
0000000
BOTH
00 CONS
lIED.
LIB.
CONS.
lIED.
LIB.
o rr rr
13
j .ij t~
o
21
~ ,
J-~
I
I
RUBBER PARTS
Dimensions are inside diameters. Numbers in
parentheses indicate quantity used, if in
exces s of one.
A. R-521-2 1-1/2" Dia. (5)
0 B. R-521-3 2" Dia.
C. R-521-4 2-1/2" Dia. (6)
D. R-406·3 Flipper (2)
E. R-243 5/16" Dia. (4)
PANEL TOP PARTS
1. Arch Rail M·1774
2. Rail Post _ C-907
3_ Rail Post Cap . . . . C-908
4. Bottom Arch P-5871-57
5. Shoote r Gauge. . . . . . .. P-6359-23
6. Bal l Gate . . . . . . . . .... A-1475-9
7. Ball Rebound . . . . . . .. AS-493-6
8. Screened Plastics . . . . .. M-133Q..141
9. Drop Target Ass'v, (R) .. AS-2795-44
10. Drop Ta rget Ass'v . (l) .. AS·2795-45
11. Thumpe r Cap (2) A-3713-29
12. Thumper Cap (Yel.) (2) .. A-3713·35
13. Ball Guide (2) . . . . . . . . M-121-18
14. Ball Guide _ M-121-25
15. Ball Guide (2) . . . . . . . . M-121-30
16. Ball Guide M-121-43
17. Bal l Guide M-121-44
18. Bat ! Guide (2) M-121·53
19. Ball Guide (2) M-121·65
20. Rol lover Wire (6) . . . . . . AS-2806
21. Outho le Wire AS-2806-21
22. Guide Rail Ass'y. (R) A-3032-24
23. Guide Rail Ass'y. (L) A-3032-25
24. Plastic Guide (2) C-935-1
25. Flipper & Shaft Ass'y. (2) AS-2214·24
26_ Rol lover Wire (2) .. ~ . . . AS-2806-24
27. Bal l Guide (4) M-121-32
CONS . - Conservat ive
MED. - Medi um
LIB. - liberal
Indicates movable posts for
scoring adjustments.
WHEN ORDERING PART,
SPECIFY PART NO.
AND NAME OF GAME
39
