1
P-294~296
P.C. Board, M-645-392
3
R',R3,RS,R7,R9,R",R34
E-105-226
Resistor, lOOK
4 R14, R16, Rl8, R20, R22,
E-l0S-227
Resistor,3OOK
R24, R2S. A35, R3S, R37,
R38.R39,R40
5
R43.R44,R4S,R46,R47,R48
E-105-228
Resistor, 9_1K
6
R13, R15, R17, R19. R21,
E-l05-229
Resistor,l.SK
R23,R2S
1
R27. R28,
Rl9,
R30, R3l,
E-105-2aO Resistor, 1K
R32.R33
8
R41
E·l05-231
Resistor,39K
9
R42
E·l05-271
Resistor, 240K
10
11 Cl, C2
E-586-65
Capacitor, .01 MFD
13 07, 08, 09, 010,
on
012
E-S8S-32
Transistor (2N5401)
14 01,02, Q3, 04, 05, 06, 013,
E-585-33
Transistor (MPS-A42)
014, 01S,
ore.
017, 018, 019
16 VRl
E-S98-7
Zener Diode, 110V
11
Ul
E-620-38
I.C. Decoder
18
19 Jl
E-715-34
10 Pin Wafer Pin Connector
21
DSl
E-680
Digital Display Panel
22
M-1836
Hi-Lo Screw, W/H
23
P-2399
Display Mounting (Top)
24
P-2399-1
Display Mounting (Bottom)
26 R2,R4,RS,R8,Rl0,R12
E-t05-287
Resistor,2.2K
27
R49,R50,R51,R52,R53,R54
E-105-242
Resistor, 20K
28
Wire Jumper
NOTE: INTERCHANGEABLE WITH AS-251S-1S
