MATCH (00-90) UNITS CONT ACT .PLATE
(WIRED) wiPER ASSY
New Type column 3,poge 94 See page 94
RATCHET
See page 94
WASHER FOR
WIPER ASSY.
P·H01-107 ~~~~~~--------------~--~~-----,
RESET PAWL
P·3382
CORE PLUG ASSY.
A·613·J3
TORSION SPRING
SP-401
COIL
STOP PLATE
P-3386
SPRING
See page 94
BELL STRIKER ASSY.
A-28SS
BELL MOUNTING BRACKET
P-6253 -1
See page 94
TO SILENCE BELL
BELL ASSY.
A-2BS9
SECURED BY
NUT
N·l032-1110
WASHER
PW.I0-10
WASHER
P-801·15
SECURED BY
PIVOT PIN
5.737-48
AND
ELASTIC
STOP NUT
M·319-3
Loosen Bell by turning ill ~ouD[er;.c1ockwise dire cricn.
Lower Bell to bQuom of slot in m 0 u n lin g-brad :c r .
Tighlen Bel l by fuming an clockwise directio n.
ADJUSTMENTS
See adjustme nt instructions, page 97.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
