"G" TYPE INTERLOCK RELAYS
Other "G" Type Relays shown on page 49
SPRING RETAINER
BRACKET
SEE PAGE 88
SPRING
SEE TABLE BELOW
TRIP RELAY
ARMATURE
~~ ---EYELET
SEE PAGE 88
TRIP RELAY
FRAME
SEE PAGE 88
INTER LOCK REL AY
FRAME
SEE PAGE 88
COILS
PART NUMBERS
MARKED ON WRAPPER
SECURED BY LATCH RELAY
ARMATURE ASSY.
SEe PAGE 88
SWITCH ACTUATOR
see PAGE 27
SWITCH BASE
SEPARA TOR
SEE NOTE BELOW
SWITOH BASE SEPARATORS
Switch Base Sepa rators , used only as required , are 9/16 in.
by 5/16 in. with 2 hole s for switch screw.
1/32 in. thick (approximately) ... 5MB ·l
1/16 in. thick (appro ximately ) ..• 5MB·2
SPRING TABLE
COLOR PART NO.
Natura l (no t dyed) SP-199-28
Red SP'199-29
Green SP-199·30
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
