ALTERNATOR UNITS
2 (DINS PER PLA Y SPRING PLATE
P.137·12
PLUNGEW
SWITCH
ASW-M- 100-1
MALE CONNECTOR
E-140-1
CORE PLUG ASSY.
A-613-92
... •. .•. •... .... .. .. ...•. .• .• .•.
I o D
BASE PLATE ASSY STOP PLATE
A -2214·16 ON OPPOSITE S'IDE OF ASSY_
P-5222·1
"Starred components constitute Or ive Pawl Assv. AS·2293-2
and may be purchased separately or as complete Assy,
AS-2293-2. .
SCREWS" WASHERS
Screws and washers should be ordered by name or
description with reference to (a) name of game, (b)
Alternator, (c) part which fastener secures.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
