SWIVEL· TYPE FREE·BALL GATES
CD
Base Plate
P·3691·18
CD
Core
Plug
Assy . . . . . . . . . . . . .
A·613·67
SECURED BY
~
~
@
®
®
@
Lockscrew (2 used)
LS·832~5·810
Coil
_ "
AF·27·1000/32·1300
Coil
Bracket
p .,
08·53
SECURED BY
Lockscrew (2 used)
LS·832·5·810
Plunger
S-496-167
Guide R;ng (not visible)
C·342
Spring, Compression ........•
SP·240·2
Roll
Pin
P·1637·1
Lever Arm Assy . .
A·1889·8
Set
Screw
(2 used) .. . . . . . . . . M·1369
Bearing,
Nylon ...•.•••.....
C-049
SECURED BY
Screw (3
used)
"
LS·632·5·510
®
Stop Bracket
P·6256
SECURED BY
Lockscrew
(2
used)
LS·832·5·810
@
Switch Bracket
P·126·S59
SECURED BY
Screw
(2
used)
LS·632·3·511
®
Switch _
_
_ .. SEE PAGE 196
OR'OER
SWITCH
SCREW
BY
NAME
With
reference
to
(a) Free Ball Gate,
(b)
Name of game,
Ie)
Switch
®
SWitch Plate (Spring)
P-131-5
®
Shaft . _.•...
_.... _. _. . . . .
S-907-5
®
Retaining Ring (2 used)
P·6316·5
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
