SOUND COMPONENTS
GONG ASSYS.
GONG ASSY. AS-385-8
BELL P-748-5
SECURED BY
NUT N·l032·1110
NO. 1.0LOCKWASHER
PLAIN WASHER PW·l0
LARGE WASHER P·801·15
BRACKET ASSY.
A·166·6
COl L BRACKET
SECURED BY
LOCKSCREW
LS-632-4-510
PLUNGER & RIVET ASSY.-_~~
A-316-22
COIL
CB-31-2000
COIL BRACKET
P-l0842
HORN ASSY.HORN ASSY. AS-2854-1
Bracket P-126-726
Connector, Male , £-140·2
Horn, 6V., A.C _ M·1795
Screw ..•.........•........... LSPR-832-1103
KNOCKER ASSY.
KNOCKER ASSY. AS-2404·7
Similar to Kickback Assy,
page 183 with
Coil _.. ' A-27-1300
Coil Bracket _ pol 08-53
SECURED 10 KICKER FRAME
BY 2 SCREW __ .. _...•...•... SFPR·00832-IlO·
Kicker Frame _ _ __ . P·7378-1
Plug Bumper _ R·23j·11
Plunger & Striker Assy. . .. __ A·SSO·S
SOUNDER ASSY.
SOUNDER ASSY. AS·73 1·9
NUT N-832·111 0
NO. S SPLIT LOCKWASHER
o
o
Sp · 200 · 7-----,,
SPRING
(NOT VISIBLE.)
CORE PLUG ASSY. A-613-91
MOUNTINGBRACKET P~7377-~
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
123
