STEPPING UNITS,
FUL
RESET COIL
C·28·ll00
TORSION SPRING
SP.370
SOLDER LUG
P-40S- 14
VARIABLE
COMMENCING WITH·
CAPT. FANTASTIC
PAGE 101
RESET
PLUNGE R
- -Lm ~ !!!!!!!ffl
5-496-101
RESET
PAWL
A-l766
SPRING
See page 100
SPRING
BASE·PLATE ASSY.
A·1768·43
RETAINING
RING
P-33B9
SECURED BY
PIVOT PIN
5-737-48
AND
ELASTIC
STOP NUT
M-319-3
Operate Reset Plunger by hand until Ratchet resets to zero
position. t.e., until resetting movement
stops. Then operate
Step-up Plunger, and while holding Step-up Plunger in.
check to see that Reset Pawl Jests at base of ratchet-tooth
(point at which straight and angular edges of tooth meel).
If Reset Pawl is not at base of tooth, adjust Spring-Stop
(.P-3384) until Ratchet
moves into position to permit Pawl
properly to engage tooth,
as described. Then check unit
RESET
CONT ACT·PLATE WIPER ASSY-
(WIRED)
See page 100
SPRING STOP
P·3384
,._--
WASHER
FOR
WIPER ASSy.
F-801·107
SWITCH
See page 100
CORE PLUG
ASSY"
I
A-613-33
STEP-UP
COIL
8-26·1100
P-1158-6
SPR
ING-WA
SHER
(Not Vis
ible)
C-342
GUIDE~RING
(Not Visible)
STEP-UP
PLUNGER
S-496-
100
M-254
RATCHET
See page 100
manually by operating Step-Up Plunger.
After
Reset Pawl
drops into position described above" Step-Up Arm should
over-ride approximarely
1/64 in. before being stopped by
Step-Up Arm Sto p ("ear" formed In Base Plate). Bend Slop
Ql1&
way or another to reduce or 'increase over-ride tu
<lP'"
proximately
11'64
in. Reset Pawl should then properly drop
into base of tooth,
without
binding, when Reset Plunger is
lightly
operated (without
pushing Plunger all the
way
in ).
WHEN ORDERING
PART~
SPECIFY PART NO.
AND NAME OF GAME
99
