SPINNER UNIT INDEX
CD Spinner Unit Assy,
In FIRECRACKER. . . . . . . . . . . . .. AS·2594
As described, Column 3, page 150,
with reference to illustration, page 149
pIus following parts, illustrated on page 151
® Spinner & Switch Assy AS·2592
SECURED TO BASE PLATE
WITH 2 LOCKSCREW LS-632-4-510
consisting of
® Cotter Pin . . . . . . . . . . . . . .. M·1536
@ Spinner Assy . . . . . . . . . . . . . . . . . .. A-3460
® Spinner Bracket P-7631
® Switch. . . . . . . . . . . . . . . . . . . . . .. ASW-A120-1
SECURED TO SPINNER BRACKET
(1) Switch Plate P-137-5
® Washer, Nylon (3 used) P-801-555
® Spinner Cam Assy . . . . . . . . . . . . . . . .. AS-2596
SECURED TO RATCHET SHAFT
WITH SHEET METAL SCREW,
PHILLIPS TYPE A No.8 x 3/4 in. long
consisting of
@) Cam P-7629
SECURED TO SUPPORT DISC.
WITH 3 LOCKSCREW LS-832-5-510
AND 3 PLAIN WASHER . . . . .. PW-8-11
® Hub C-260
SECURED TO SUPPORT DISC
AND TO WASHER P-801-107
WITH 2 SCREW MS-540-11-110 WITH 2 SCREW MS-440-4-212
@ Support Disc _ , .. P-7630
@ Washer. . . . . . . . . . . . . . . . . . . . . .. P-801-107
@ Washer. . . . . . . . . . . . . . . . . . . . . .. P·258·23
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
