STEPPING UNITS, FULL RESET
CONTACT-PLATE WIPER ASSY
(WIRED)
.
TORSION SPRING
SP-370
SOLDER LUG
P-405-14
RESET
PLUNGER
--L..t*~~fl
S-496-101
RESET
PAWL
A-1766
SPRING
See page
150
SPRING
See page
150
SPRING STOP
P-3384
WASHER FOR
WIPER ASSY.
P-801-107
SWITCH
See page
150
CORE PLUG ASSY.
I
A-613-33
STEP-UP COIL
See page
150
P-1158-6
SPRING-WASHER
(Not Visible)
C-342
GUIDE-RING
(Not Visible)
RETAINING
RING
P-3389
STEP-UP
PLUNGER
S-496-100
BASE-PLATE ASSY.I---f---;=~~=~:----"\~~~
A-1768
IN JOUST
AND
EARLIER GAMES·
IN BALLYHOO
AND
LA TER GAMES
*
SEE PAGE 150
SECURED BY
PIVOT PIN
$-737-48
AND
ELASTIC
STOP NUT
M-319-3
Opera te Rese
t
Plunger by hand un til Ra tche
t
resets
to
zero
position, i.e., until resetting movement stops. Then operate
St~p-up Plunger, and while holding Step-up Plunger in,
check to see that Reset Pawl rests at base of ra tchet-tooth
(point at which straight and angular edges of tooth meet).
If Reset Pawl is not at base of tooth, adjust Spring-Stop
(P-3384) until Ratchet moves into position to permit Pawl
properly to engage tooth, as described. Then check unit
RATCHET
See page
150
manually by operating Step-Up Plunger. After Reset Pawl
drops into position described above. Step-Up Arm should
over-ride approximately 1/64 in. before being stopped by
Step-Up Arm Stop ("ear" formed in Base Plate). Bend Stop
one way or another to reduce or increase over-ride to ap-
proximately 1/64 in. Reset Pawl should then properly drop
into base of tooth, without binding, when Reset Plunger is
lightly operated (without pushing Plunger all the way in).
*
See chr onologica l list of game s, page 6.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
149
