"G"
TYPE RELAYS
UG"
Type Interlock Relays shown on page 135
SWITCH
ACTUATOR
SEE PAGE
42
SPRING RETAINER
BRACKET
P·7491
::::'-1-5::::""=;;""_
SWIT CHI NG
~~~
SEE PAGES 80, 83
SPRING
SEE TABLE BELOW
SWITCH BASE
SEPARATOR
SEE NOTE BELOW
EYELET
GROMMET
SEE PAGES
80, 83
COIL
PART NUMBER
MARKED ON WRAPPER
SECURED BY
8·32
x
3/8 IN. LONG
WASHER HEAD
HEXAGON SEM-SCREW
AND
BRASS WASHER P·801·149
FRAME
SEE PAGES
80,
83
SWITCH BASE SEPARATORS
Switch Base Separators, used only as required. are 9/16 in.
by 5/16
in.
with
2
holes for switch screw.
1/32 in. thick (approximately)
5MB·1
1/16 in. thick (approximately)
5MB"2
SPRING TABLE
COLOR
PART NO.
Natural (not dyed)
SP·199·28
Red
SP·199·29
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
