NOTE A
Coin Switch
&
Rejector Mounting Assy. AS-277-137
illustrated on page 13, is used only with
Single Coin Chute,
BIG VALLEY through* SEA RAY
Other Coin Switch
&
Mounting Assys.
are detailed in NOTE A, page 16.
ALSO SEE PAGES 11-14
NOTES
When ordering complete Assy., specify
(a) Coin, as stated in NOTE C,
(b) Coin Guide,
as
stated in NOTE D,
(c) Coin Guide Spacer, NOTE D.
NOTEC
Coin Switch is either
£-108-92 or
£-108-98,
depending on weight of coin. If not sure of correct part
number, order Coin Switch by name with reference to (a)
coin denomination, (b) name of game.
NOTE 0
To determine correct part number of Coin Guide and Coin
Guide Spacer refer to International Coin Mechanism Data,
commencing on page 23.
SCREWS
Order screws by name or description with reference to
(a) AS-277-137,
(b) part screw secures.
"Se e chronological list of games, page 6.
