ROLLOVERS
Right
P-6254
TWO-DIRECTION ROlLOVERS
P·6254·1
ONE·DIRECTION ROLLOVERS
T e n s ion of Roltover- Sw irc h blades which contact
Auu3[Qr should be ad jus red to insure lhat Ball roi ls
over Ac[uator [ r e e l y, without hesitating Of stopping.
WIRES NOTE A
Depend ing on app l ic at ion, * 133G or M-l3 36· 10
may be used. Wires may be re c ogni zed by d irnen-
s iona l di fferenc~s ind ic aced in red u c e d s iz e
sketch below. M-1336 and M-1336·IO cannot be
used interchangeably.
Double-check Playfield Charts, commencing page
185, for exact part numbers of Rollover Wires.
ROLLOVER BUTTONS
I
I
I
I
I
I
I
2-5/32' .__.:
See Playfield Charts, commencing page 185
M·1336-10
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
