NOTE A
Coin Switch & Rejector Mounting Assy.
TRIO
and earlier games*
Nat available
BLUE RIBBON
through"
BOWl-O .....
AS-277-97
As illustrated, page 15
BIG VAllEY
through*
MARINER
With Single Coin Chute. . . . . . . . . . . . . . .
AS-277-137
As illustrated, page 17
With Multiple Coin Chutes
AS-277-135
Same as AS-277-97, page 15, with
ADDED COMPONENTS
Lockout Wire
M-1504
Lockout Wire Bracket . . . . . ..
P-6629-49
CHANGED COMPONENTS
Slug Rejector Mount Assy.
A-1388-47
REMOVED COMPONENTS
(ADDED TOFRONT DOOR)
Push Button Assy. . . . . . . . . ..
AS-2377-1
Slug Rejector Mounting Bracket
P-6046·8
FIREBAll
and later games·
See pages 11-14
NOTE B
When ordering complete Assy., specify
(a) COin, as stated in NOTE C,
(b) Coin Guide, as stated in NOTE D,
(c) Coin Guide Spacer, NOTE
D.
NOTEC
Coin Switch is either
E-I08-92 or
E-I08-98
depending on weight of coin. If not sure of correct part
number, order Coin Switch by name with reference to (a)
coin denomination, (b) name of game.
NOTE
0
To determine correct part number of Coin Guide and Coin
Guide Spacer refer to International Coin Mechanism Data,
commencing on page 23.
SCREWS
Order screws by name or description with reference to
(a) AS-277-97 or AS-277-135,
(b) part screw secures.
LATCHMAGNET ASSY. AS·2517·2
USED WITH COIN SWITCH
&
REJECTOR MOUNTING ASSY. AS-277 -135
SEE NOTE A ABOVE
CD
Magnet Frame •••••••••••••
P-722S-3
a>
Fishpaper Insulator •••••••••
P-15Q-.IOO
®
Screw. Hexagon Head, Brass ••• No. 8·32x3/8 in.
With External Tooth Lockwasher
@)
Coil ••••••.•.••...•.
__ . FC-33-2600
®
Spring _ .••••..••••.•.
_ .. SP-I00-276
®
Lockscrew (2 used) •..
_ . _ .• _ LS-832-3-S11
(J)
Armature (Latch) _ •.••...
__ • P-7207-3
®
Armature Plate .........••.
P-7326
®
Lock-out Strip (NOT SHOWN) •..
P·7327
LOCK-OUT STRIP,
WHICH ENGAGES ARMATURE PLATE,
IS NOT INCLUDED
IN LATCH MAGNET ASSY. AS-2517-2
.See chrono logical list of
games,
page
6.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
16
