INDEX TO ILLUSTRATION, PAGE 269
CD Mat & Disc Assy . . . . . . . . . . . . . . . .. AS-26gB
SECU RE 0 TO Motor Shaft
by 2 Set Screws, Slotted,
Hexagon Head M-1590
@ Hub & Disc Assy A-356B
@ Rubber Mat. . . . . . . . . . . . . . . . . .. R-226-16
SECURED TO Disc
with rubber cement
@ Motor......................... E-119-425
SECU RED TO Motor Mounting Bracket
by 4 Lockscrew . . . . . . . . . . . . . . .. LS-832-6-511
and 4 Plain Washer. . . . . . . . . . . . .. PW-8-10
® Motor Mounting Bracket P-7807
® Mounting Bracket (2 used) . . . . . . . .. P-7801
SECUR ED TO Motor Mounting Bracket
by 2 Lockscrew .. . . . . . . . . . . . . .. LS-832-4-511
and 2 Plain Washer. . . . . . . . . . . . .. PW-8-10
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
270
