KICKBACK ASSY. AS·1587·69 (FLIPPER TYPE)
Item 1 through 4 constitute Kickback Arm Assy_
AS-2381-3, which is used with but is not a part of
Kick back Assy_AS-1587· 69_
CD Kickback Arm & Shaft Assy_ A-2747·7
CD Anvil - - - - - - __ - - - - . _. - .. S-1952
@ Rubber Ring .. _ _" R·392
® Screw _.... LS-1032·14-511
® Bearing, Nylon __ . _ C·649
® Screw (3 ussd) . . . . . . . . . .. MS-632-5-510
( i ) Bracket - . - .. - - . - . - P-6Z56
® Rol Pin P·1637·J
® Set Screw (2 used) _. . .. M·1369
@ Lever Arm Assy _. . . .. A·1889·8
@ Plunger __ ... _ _. . .. S-496-167
® Coil.. .. . . . . . . . . .. . . . .. A-26-1200
@ Core Plug Assy. __ . . . ..... A-613·67
@ Screw (6 used) . _. . . . . . . .. LS-832·5-510
@ BasePlate _.. P-3691·18
@ Solenoid Bracket _ __ . .. P·108-53
® Guide Ring (not visible) ... _ C·342
@ Spring, Compression .. ____ SP·240
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
