FLIPPER-ZIPPER: RELATED PARTS
FLIPPER & PIN ASSYS.
Left AS·2214-7
As illustrated, page 205, with
Flipper _ C·60g..5
Flipper Arm Assy A-2747-4
Right _ AS·2214·6
Same as AS-22 I4--7, above, excepting
Flipper C-610-5
IMPORTANT
Although above Flipper & Pin Assys. are normally used
with Flipper Zipper, check pages commencing with p,'ge
246 for possible game to game variations.
FLIPPER BUTTON ASSY.
See page 245
RUBBER RINGS
See Playfield Charts, commencing page 185
SWITCH & BRACKET ASSY.
When listed under name of game
pages 246, etc. .. . . . . . . . . . . . . . . . .. AS-982-588
Bracket , .. , , . . . . . . .. P-126-548
Switch,
LISTED FROM SWITCH PLATE END OF 8T ACK
Top , . . . . . .. ASW-A2-39
Bottom , . . . . . . . .. ASW-All-3
Switch Plate (Spring) . . . . . . . . . . . . .. P·137-5
Switch Screw (2 used) . . . . . . . . . . . .. MS-540-20-510
When listed under name of game,
page 246, etc. AS-982-894
Same as AS-982-588, above, excepting
Switch,
LISTED FROM SWITCH PLA TE END OF 8T ACK
Top. . . . . . . . . . . . . . . . . . . . . . . . . . .. ASW-A2-50
Middle . . . . . . . . . . . . . . . . . . .. ASW-A2-39
Bottom. . . . . . . . . . . . . . . . . . . . . . . .. ASW-A11-3
Switch Screw (2 used) .... _. . . . . . . . .. MS-540-24-S10
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
