3·STEPS FREE·BALL ESCAPE ASSY.
AS...2300 ...2 in FOUR MILLION B.C.
Similar to Assvs, on opposite page
with following parts:
Arm & Stud Assy.•....•..•...•...•.•..•.•. A·2870·2
Ball EscapementPlate AssY.,
Single Prong .......................•... A·2871·S
Double Prong 12used) .......•.. , .••.. , .. A·2871·3
EscapementBracket Assv.......•.......•.... A·2877-2
Guide Ring ••...•.•.••....•..•••. , ..•• .•. C-342
Link. . • • . • • . . . . . . . • . . . . . . . . . . . . • . . . . . .. P·6442·80
Nyliner (6 used) . . . . . . . . . . . . . . . . . . . . . . . . .. C·537·3
Plunge r 5·496-168
Retaining Ring (8 used ) . . . . . . . . . . . . . . . . . . .. P·63164
Roll Pin... .. .. P·16 37·10
Spri nq, Extension. . . . . . . • • . . . . • . . . . . . . SP·100 ·233
Washer 12used) ..........••.••............ P·80l-521
At connect ion of
Arm & Stud Assv, with Link
COIL & BRACKET ASSY.
AS~2299
USED WITH ABOVE ASSY.
243
