SWIVEL· TYPE FREE·BALL GATES
1)
CD
Base Plate,
THE WIGGLER
P·3691·20
Other games, next page
P·369l·l8
CD
Core Plug Assy . . . . . . . . . . . . . A·61 3·67
SECURED BY
CD
ffi
®
®
Lockscrew (2 used)
LS·832·5·810
Coil
AF·27·1000i32·1300
Coil Bracket . . . . . . . . . . . . . . .
p .,
08·53
SECURED BY
Lockscrew (2 used)
LS·832·5·810
Plunger
5·496·167
Guide Ring (not visible)
C-342
Spring, Compression
SP-240-2
Roll Pin
_.. P·1637·1
Lever Arm Assy.,
DOGIES
A·1889-l5
Other games, next page . . . . . A·1889·8
Set Screw (2 used)
M·1369
Bearing, Nylon
_. . . C·649
SECURED BY
Screw (3 used)
_.. _. LS·632·5·510
®
@)
®
Stop Bracket _.............
P·6256
SECURED BY
Lockscrew (2 used)
LS-832-5·8l0
®
Switch Bracket
_ P-126-559
SECURED BY
®
Screw (2 used) . . . . . . . . . . .. LS-632-3-511
Switch
SEE PAGE 238
ORDER SWITCH SCREW BY NAME
With reference to
(a) Free Ball Gate,
(b) Name of game,
(c) Switch
Switch Plate (Spring)
_. __ P-137·5
Shaft
S·907·5
Retaining Ring (2 used)
P·6316-5
®
®
@
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
