BALL·EJECTOR ASSYS.
Effective with ON BEAM and later games *, variations in Ball
Ejector are described on this page.
If part number is not known for variable component in GATOR
and earlier gomes* I order by nome or desuiption with reference
to (a) name of Assy., (b) location of Assy., (c) name of game.
ON BEAM BIG VALLEY
Ball Re turn '.' . AS ·428·27
As illustrat ed, page 235
Ski ll Kicko ut . . . . . . . . . AS ·428·24
As illustrat ed, pa ge 229, with
Coil ,. , A·27·1100
Mount ing Bracket Assy .. A·64 3·9
Spr ing (8all Ki ck er AS'Y.) SP·199 ·11
JOUST
Ball Return AS ·428·22
As Illust rated , pag e 229 , with
Coil A·25 ·'050
Mou nting Brac ke t Assy .. A·643 ·9
Sp ring (Bal l Kick erAssy .) SP ·199 ·11
Ski ll Kickou t . . . . . . . . . . .. AS ·42 8·24
Same as Skill Kickout , ON BEAM
BALLYHOO
Bal l Retu rn , AS ·428·22
Sam e as Bal l Retu rn , JOUST
Skill Kickou t
Center Lef t. . . . . . . . . . .. AS·42B ·22
Same as Ball Return , JOUST
Top Left AS ·428 ·28
As illustra ted. page 229 , with
Coil. . . . . . . . . . . . . . .. A·27 ·13 00
Mou nting Bracket Assy . A·64 3·7
Spr ing (Bal lKick erAssv) SP ·199 ·11
KING TUT
Bal l Return .
Same as Ba ll Retu rn, JOUS T
AS ·428 ·22
KING REX
Ball Return .
As illustuted , page 235
AS ·428 ·27
GALAHAD
Bal l Return . AS·428 ·22
Same as Ball Return , JOUS T
Sk ill Kickout (2 used) AS ·428·28
Same as Skill Kickou t, Top Left ,
8ALLYHO O
CAMELOT
Same as in GALA HAD
BOWL·O
Ball Ret urn , ,. AS·428 ·22
Same as Ba ll Ret urn, JOU ST
Sk il l Kickout . . . . . . .. ... AS ·428 28
Same as Skill Kickout , Top Left ,
BALLYHOO
Ball Return AS ·428 ·25
As illustrat ed , page 229 , with
Coi l A-25 ·10 50
FIRECRACKER
Bal l Return
As illustra ted, pa ge 22 9, with
Co il .
Mount ing Bra eket Assy ..
Spr ing (8all Ki ck er Assy.)
Sk ill Kic kout (3 used )
As illustra ted. pa ge 229. with
Coil
Mount ing Br acket Assy .
Spring (Ball Kicker Assy.)
AS ·428 ·30
A·26·1100
A·643 ·9
SP·199 ·27
AS ·42B ·31
A·26 ·1100
A·643·7
·SP·199 ·11
Ball Ret urn. . • . . • . . . . . . .. AS·428 ·30
Same as Ball Return , FI RECR AC KER
Sk ill Ki ckout (2 used) .•. ... AS ·428-31
Sam e a, Sk ill Kickout, FIRECRA CKER
Ball Return. • . . . . . . . • . . .. AS·428 ·30
Sam e as Ball Return , FIRECRAC KE R
Skill Kickout (1 used) AS ·428 ·31
Same as Skill Kickout , FIR ECRACK ER
Ba ll Return
Bal l Re turn Kicker . . . . . .. AS·269 4
As illustra ted. page 22 8
Skill Kickout (2 us ed) . . . .. AS-42 8-28
Same as Sk ill Kickout , Top left,
BALLYHOO
AS ·2694
