BALL·RETURN KICKER ASSY. AS·2694
ALSO SEE BALL-EJECTOR ASSYS., PAGE 229
AND LISTING, PAGE 230
1. BasePlate Assy. A-3546
2. Coil A-25-1050
3. Core Plug Assy A-613-67
SECURED TO BASE PLATE
BY 2 SCREWS, SWAGE FORM,
PAN HEAD,
No.8 x 3/8 in SFS-832-06-P12
4. Cotter Pin M-1536
5. Kicker Arm Assy A-3545
6. Plunger & Link Assy. AS-2586
7. Link , P-7373
8. Plunger S-496-190
9. Roll Pin P-1637·59
10. Retaining Ring P-6316-5
11. Spring, Compression SP-200-185
12. Striker Ring C-838
BALL GUIDE PLATE P-7788
ALSO USED WITH ABOVE
BALL RETURN GUIDE (CURVED) .. P-6346-5
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
228
