FIREBALL Playfield
Chart
.,
I
e
I
I
3
Ie
I
I
0
r
2
203
RUBBER
RINGS
Dimens ions are inside o larnete rs. Numbers in
pa rentheses indicate quantity usa d,
if
in exc ess
of on e.
A R-521 -3.2 in. (5)
B
R-521-4. 2)', in .
C R-521-2.
1)',
in . (2)
D
R-521 -5,3 in. (3)
E
R-521 -1,1 in. (4)
F
R-243, 5/ 16 in . (6)
PARTS
1 BOTtom Arch •• ,.,... .
P-5 831 ·38
2 Shoot er Gaug e ..•.•. ..
P-6359 -10
3 Sid e Ra il. lef
t • •. • . • ..•
CA ·1208-16
4 S ida Rall, right .... •• .•
CA -1208 -17
5 Gu ide Ra il •••.•.. •...
P-6495 -72
6 Gu ide Rail .•. .•.••.
_. P-6495 -71
7 L ight Sh iel ds & Bushlng,
Scre ened(s et) .•.. _. A-289G -81
8 Light Shie ld s 8< Bushin g.
Clear
(s et) .. _ .• '.. _. A·2890 -82
9 Bump er Cap, yellow .. ,.. C-719 -17
10 Bumper
Ca p,
bl ue ... _. C-71 9-16
11
Ro llove r But ton . . . . • .. C-387 -5
PARTS RE LATED TO ROLLOV ER
BUTTON
Bus h ing .•.•.•..•. .•.
S-15 59 -1
Push-on Fastene, . . . . .. M -298 -9
Switch ,
Bre ak (2 used) •.•.•
ASW -A2 -4
Ma ke (6 used) .•. __ • ASW -Al -4
Switch StOp Bracket
W ith Break Switch .• P-1 26 -57 0
W ith Mak eSw itc h _ .,. P-126 -562
Washer _.... _ .. _ ... . _ P-801 -125
12 Flippe r and Shaft , right . AS -2214 -6
13 F lipper 8< Shaft. left .. _ AS -2214 -7
Items
12 , 1 3
DETA ILED ON PAGE 253
14 Rol lover W ire
M -1336 -2
15 Rol lover Wire. _ _ .• M ·1336 -9
16 Ro llov er W ire ••.. .. •.•
M -1336 -10
17 Rol lo ver W ire •• .•. ....
M- 1336 -13
BRACKETS FOR ITEMS 14,1 5,16,1 7:
See page 27 5
SWITCHES FOR ITEMS 14, 15 ,16 .17 :
See page 36, etc . .
18 Sail Guide W ire
M -121 -18
19 Sail Guid e W ire •.. •.
,. M -1 21 -34
20 Sai l Guida Wire. _. _. _. M -121 ·37
21 BaU Gu ide W ire _.... ..
M ·12 l-38
22 Bal l Gate & W ire As$Y •. AS -22 5O -12
Deta iled, Item 13, page
187
23 Ball Gate
&:
W ire Assv , ..
AS -22S0-24
Deta ile d, Item
18,
page 194
24 Ball Gate & W ire Assy .. AS -22SO- 29
Brac ket . _ .... _ . . .. P·586 7-12
Wire ... _ . __ . _ . . .. M -1272 -29
25 Ch rome Plate . _ . . . . . .. P·5899-7
26 Mush roo m Bumpe r ...•
AS -2291 -10
Ca p, bl ue _. _ .•..
C-6l6 -10
Eyelet
_ .. _ . _ .• M -1 22-13
Post .. ... •..•.•..
C-617 -8
Ret a ining R ing
P-2891 -4
Rubb e, R ing
_ .. R·392
Spring
_ . . . .. SP -200 -162
27 Mushroom Bumper. • . .• AS -2291 -11
Sarna as
Ite m
26,
above ,
ex ceo
ti
ng
Gap .yel. low .. _ .... _ C- 616 -17
28 Gu ide Rai l ... _ .. .••..
P-6244 -52
29 Gate W ire .•....
_ . . . .. M- 133S -1
30
Protect ive W ire _ . _ . . . •• P-7639
31 S tiffene r Bracket ,.....
P-1973 -295
(NOT SHOWN IN CHART)
32 Ramp Hood _ . . . • . • • .. P .7803
33
Ramp End.... •... ....
P-7800
(UNDER HOOD)
34
Ram pSupport (Front) .• P-7 806
35 Ramp Suppo rt
l
R .ear). .• A-3569
(NOT V ISIB LE IN CHA RT)
(LOCATED ON BOTTOM OF
PANEL)
36 Sp inner Assy
_. A5 -2699
ILLUSTRA TED. PAGE 269
